Tow Bar Falcon - 522

  • Image 1
  • Image 2
RRP:
$1,019.99
Your Price:
$865.00 (You save $154.99)
Brand:
Weight:
60.00 LBS
Shipping:
Calculated at checkout


Product Description

The Falcon All-Terrain was designed, tested and manufactured to the highest standards. It weighs just 35 pounds, yet pulls up to four tons. A unique eggshell design distributes pressure throughout the tow bar, making the Falcon All-Terrain the world's strongest aluminum tow bar with steel and stainless steel at every critical point to further ensure superior strength and structural integrity. The Falcon All-Terrain is easy to connect, and its stainless steel inner arms telescope, center and automatically lock as you pull away. Once you've reached your destination, a unique storage lock secures the Falcon All-Terrain in its stored position.

The Falcon All-Terrain comes complete with safety cables and power cord. Both are routed through a center channel for added safety, convenience and a clean, uncluttered appearance. Beyond its many performance features, the Falcon All-Terrain is aesthetically pleasing — its powder-coated finish and sleek design complement your coach and your car. As well they should — the Falcon All-Terrain exemplifies ROADMASTER’s highest standards, as well as yours.

  • One-person quick-connect and disconnect
    • At the towed vehicle: Thanks to an exclusive, self-supporting quick-disconnect system, one person can easily connect or disconnect the Falcon All-Terrain in seconds. (These brackets also make it extremely easy to attach accessories such as the Guardian™, Stowaway and the Tow Defender).
    • And at the motorhome: Telescoping, independently-adjustable inner arms are easy to maneuver into position. Simply pin them in place and then drive your motorhome away and the arms automatically center and lock in place.
  • The largest hook-up radius in the industry means you don’t waste time lining up your towed vehicle. You can’t say this about many things in life but connecting the Falcon All-Terrain is just like horseshoes — “close” is good enough!
  • Self-lubricating polyurethane bushings eliminate friction between the inner and outer arms for smooth, easy operation. Other tow bars have steel riding on steel.
  • Patented storage latch: Simply fold the Falcon All-Terrain toward the motorhome and the storage latch will click, automatically locking it in place. When you’re ready to tow, just lift the tow bar up and press the storage latch to release the lock.
  • Channel guides: The safety cables and power cord are both routed through the built-in channel guides for protection against damage or dragging, and for a clean, uncluttered look. There’s no need to wrap the cables or the power cord around the tow bar every morning.
  • Motorhome-mounted: When you reach your destination, the Falcon All-Terrain conveniently stores out of the way on the back of the motorhome.
  • No ball mount to drag: The Falcon All-Terrain mounts into a 2-inch receiver.
  • Solid stainless steel inner arms: Solid stainless steel inner arms for smooth, trouble-free operation and easy maintenance. Stainless steel looks better, lasts longer and prevents corrosion that binds — ROADMASTER tow bars are the most rust-free in the industry.
  • Full-length steel crossbar — reinforced for maximum support and safety.
  • A lustrous, high-tech powder coat finish for maximum durability. This finish exceeds all 500-hour salt spray, high-impact and extreme weather standards. In this process, charged particles of pigment are sprayed onto the surface of the tow bar, then baked at more than 400 degrees. The paint fuses to the metal. The result is a uniform, thick and extremely durable finish — three times stronger than solvent-based paint.
  • Relentless testing
  • ROADMASTER was the first towing products manufacturer to use computerized testing — as well as “real world” physical testing — to ensure structural integrity, longevity, and the safety of your family. ROADMASTER’s computerized testing method is called “FEA,” which stands for “Finite Elemental Analysis.” If that sounds complicated, that’s because it is — FEA is the same method NASA scientists use to test their new designs. The automotive, architectural and biomedical industries, among others, also use finite elemental analysis.

Every FEA design is displayed as a full-scale, three-dimensional object, which engineers can rotate and study on the screen as they apply thousands of pounds of force across the load-bearing components. Stress in the steel is pinpointed, and the design is manipulated to remove it. The result is an optimized design, in both materials and components, which has been tested and verified at maximum linear strain.

Freedom Latch™ non-binding technology

No more binding!

If everything has to align perfectly to release your tow bar, ask yourself this question: Why are you making life easy on your tow bar? Shouldn’t it be the other way around? The plain fact is, unless you’ve got a pair of Freedom Latches, your tow bar locks are eventually bind. And they’re going to do it at the worst possible moment. So avoid that whole unpleasant scenario and get a Non-Binding tow bar. Like this one.

A patented cam design inside the Freedom Latch transforms linear motion into rotary motion at a 400-to-1 ratio — five pounds of force against the latch equals 2,000 pounds of force against the lock. So you’ll never have to straighten and align your towed vehicle and motorhome to release the tow bar — the Freedom Latch releases the tow bar at any angle or bind — first time, every time. No other tow bar manufacturer makes towing this simple.

• Made in the U.S.A.
All of our core products are designed, engineered and manufactured at our plant in Vancouver, Washington, with virtually every process done under the same roof. When we say, "we made it," that's what we mean — we didn't just assemble it; we made it.

Owner's Manual & Installation Instructions

Download
